System type: 2 frequency division 2 unit coaxial inverter box
Rated power: 550W
Music power: 1100W
Peak power: 2200W
Nominal impedance: 8 OHMS
Recommended rated output power of amplifier: 600W—1000W@8 OHMS
Nominal sensitivity (1W@1m): 99dB
Maximum sound pressure level (Pmax@1m): 126dB@550W(129 dB @900W,)
Frequency bandwidth (-10dB): 54Hz-20KHz
Nominal directivity (-6dB): 90°H×90°V
Transducer configuration: high frequency ferrite compression driver (44mm voice coil) × 1
Low frequency ferrite driver 15″(380mm driver, 65mm voice coil) ×1
Frequency division mode: Passive two-way frequency
Connector: SPEAKON NL4×2 (PIN1+/2+ POS.PIN1-/2- NEG)
Box material: 18mm (0.7″) high-grade birch plywood
Color: The default is black water-based paint, other colors can be customized according to requirements
Product size: W610mm*D475.5mm*H368.2mm
Weight (each): 21.95kg
Gross weight (single pack): 24.25kg
