System type: 3 units, 2 frequency division and phase inversion
Rated power: 700W
Maximum power: 1400W
Peak power: 4000W
Nominal impedance: 8 OHMS
Recommended rated output power of amplifier: 1000W—1500W@ 8 ohms
Nominal sensitivity (1W@1m): 103dB
Maximum sound pressure level (Pmax@1m): 131dB@700W(134dB@1400W)
Frequency bandwidth (±6 dB): 58Hz-20KHz
Nominal directivity (-6dB): 90ºH*8ºV for a single array module
(Note: The vertical coverage angle of the line array varies according to the degree and curvature of the array)
Adjustable angle: 0°～9°, unit adjustment angle is 1°
Recommended number of arrays: ≥4
Rated parallel number: ≤2
Transducer configuration: low frequency driver 10 "(250mm unit 65 mm voice coil) × 2
High frequency driver
3″(75mm voice coil)×1
High frequency waveguide horn
1.5 "(38 mm throat)×1
Crossover mode: passive
Connector: SPEAKON NL4×2
PIN1+/2+POS.
PIN1-/2-NEG.
Box material: 18mm (0.7″) birch plywood
Hanging hardware: professional adjustable angle hanging piece
Color: The default is black polyurea spray, other colors can be customized according to requirements
Box size: W700mm*D305mm*H500mm
Weight (each): 34.55kg
Gross weight (single pack):
kg
