System type: 2 units, 2 frequency division passive phase inversion
Rated power: 200W
Maximum power: 400W
Peak power: 800W
Nominal impedance: 8 OHMS
Recommended rated output power of amplifier: 300W—400W@8 OHMS
Nominal sensitivity (1W@1m): 95dB
Maximum sound pressure level (Pmax@1m): 118dB@200W(121dB@400W)
Frequency bandwidth (-10dB): 58Hz-20KHz
Nominal directivity (-6dB): 90°Hor.×90°Ver.
Transducer configuration: ferrite low-frequency driver 8″ (200mm unit 38mm voice coil) × 1
Ferrite high frequency driver 1″(25mm voice coil)×1
Crossover mode: passive
Connector: SPEAKON NL4×2 (PIN1+/2+POS.
PIN1-/2-NEG)
Cabinet material: 12MM (0.5”) MDF
Color: The default is black paint, other colors can be customized according to requirements
Box size: W270*D264*H420mm
Weight (each): 8.5kg
Gross weight (single pack): 9.9kg
